logoXL CI

Entirely customizable for a perfect adaptation to the user and…

The lowest seat-to-floor height on the market, 11 ½″! The XL5 offers lower seat heights and center of gravity adjustment to facilitate foot propelling.

Download the Order Form

Seat-to-floor height

The XL5ci is truly distinctive in that it features a low starting seat-to-floor height of 11 ½″.

All-In-One Footrests

  • Removable, height-adjustable swing-away footrests
  • Height- and angle-adjustable footplate
  • Folding strap for easy folding and storage

Easy Storage

Foldable into a minimal size that allows carrying and storing the chair with ease.

A multitude of options

  • Adjustable rear wheel depth
  • Axle plate offers adjustable seat height and centre of gravity
  • Anti-tippers with adjustable height and depth
  • Transit anchor points
  • Removable, height-adjustable swing-away armrests
  • Height-adjustable side guards for optimal comfort

Available Colors

Specifications

Frame Type Folding
Frame Material Aluminum
Seat depth 14″ to 22″
Seat width 12″ to 22″
Front seat-to-floor height
11 ½″ to 19 ½″
Rear seat-to-floor height 11 ½″ to 19″
Front wheel diameter 4″, 5″, 6″, 7″ or 8″
Rear wheel diameter 20″, 22″, 24″ or 26″
Transport weight* 27.6 lb
Weight limit 350 lb
Backrest height 13″ to 26″
Adjustable backrest angle range 85° to 115°
Armrest « U » Type: 8″ to 13″
« U » Type lowered: 6″ to 9″
« L » Type: 9″ to 11″
« T » Type: 8″ to 12″
Footrest 60° – 70° – 90°
Legrest Elevating/Articulating legrest 14″ to 19″
*Weight based on 16″ x 16″ wheelchair with all standard components except for rear wheels. Rear wheels are excluded since there are multiple different weights for possible wheel configurations. Example, a pair of standard 22″ rear wheels weighs 7.8 lb.
