logoXL CI

Entirely customizable for a perfect adaptation to the user and…

The lowest seat-to-floor height on the market, 11 ½″! The XL5 offers lower seat heights and center of gravity adjustment to facilitate foot propelling.

Download the Brochure

Seat-to-floor height

The XL5ci is truly distinctive in that it features a low starting seat-to-floor height of 11 ½″.

All-In-One Footrests

  • Removable, height-adjustable swing-away footrests
  • Height- and angle-adjustable footplate
  • Folding strap for easy folding and storage

Easy Storage

Foldable into a minimal size that allows carrying and storing the chair with ease.

A multitude of options

  • Adjustable rear wheel depth
  • Axle plate offers adjustable seat height and centre of gravity
  • Anti-tippers with adjustable height and depth
  • Transit anchor points
  • Removable, height-adjustable swing-away armrests
  • Height-adjustable side guards for optimal comfort

Available Colors

White

Silver

Charcoal

Matte Black

Glossy Black

Starry Purple

Plum

Candy Red

Starry Green

Candy Green

Candy Blue

Sunset Orange

Yellow

Specifications

Frame Type Folding
Frame Material Aluminum
Seat depth 14″ to 22″
Seat width 12″ to 22″
Front seat-to-floor height
11 ½″ to 19 ½″
Rear seat-to-floor height 11 ½″ to 19″
Front wheel diameter 4″, 5″, 6″, 7″ or 8″
Rear wheel diameter 20″, 22″, 24″ or 26″
Transport weight* 27.6 lb
Weight limit 350 lb
Backrest height 13″ to 26″
Adjustable backrest angle range 85° to 115°
Armrest « U » Type: 8″ to 13″
« U » Type lowered: 6″ to 9″
« L » Type: 9″ to 11″
« T » Type: 8″ to 12″
Footrest 60° – 70° – 90°
Legrest Elevating/Articulating legrest 14″ to 19″
*Weight based on 16″ x 16″ wheelchair with all standard components except for rear wheels. Rear wheels are excluded since there are multiple different weights for possible wheel configurations. Example, a pair of standard 22″ rear wheels weighs 7.8 lb.
